ACiQ 18 SEER2 Standard 36000 BTU Inverter Mini Split AC/Heating System | Ductless Mount Heat Pump AC Unit with 15ft Installation Kit | WIFI Control, R454B, 230v
Product details
| Management number | 220248664 | Release Date | 2026/05/03 | List Price | $980.00 | Model Number | 220248664 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
ACiQ 18 SEER2 STANDARD 36,000 BTU AC/HEAT PUMP MINI SPLIUpgrade your home comfort with the ACiQ Mini Split, an energy-efficient solution for year-round climate control. Inverter technology maintains consistent temperatures while reducing power use, and built-in Wi-Fi plus a handheld remote make it easy to adjust settings to fit your lifestyle in any season.Smart ComfortSleep Mode: Reduces energy use automatically over a 10-hour cycleEco Mode: Maximizes efficiency by using the least power necessaryTurbo Mode: Quickly reaches your desired cooling/heating temperature24-Hour Timer: Schedule the system to run exactly when you wantFollow Me: Uses sensor in the remote for more accurate comfortSilent Mode: Lowers operating noise levels for quieter performanceCompact & Quiet PerformanceEfficiency Ratings: 18 SEER2 | 8.5 HSPF2Sound Level (dBA): 28 Indoor | 60.5 OutdoorLiquid/Suction (Diameter): 3/8" LL x 5/8" SLElectrical Data: 230v 1-Phase 60 Hz | 33.0 MCAWidth (Indoor/Outdoor): 49.57" | 37.24"Depth (Indoor/Outdoor): 11.1" | 16.14"Height (Indoor/Outdoor): 14.25" | 31.89"Kit InclusionsOutdoor heat pump condenserIndoor wall-mounted air handlerRemote with holder and batteriesLine set and control/power cablesScrews, wrap, and drain accessoriesIndoor mounting metal plateACiQ was founded with a promise to provide quality and value in every HVAC solution. The brand has quickly expanded into a full lineup that meets every need. Each product is protected and built to deliver confidence and long-term value.
- CERTIFIED ACiQ SELLERS: Everything you need for reliable HVAC solutions!
- MINI SPLIT UNIT: This ductless mini split AC/heating system provides enough air conditioning for rooms up to 1600-2000 sq. ft. in size and is ideal for halls, restaurants, or large commercial spaces.
- 18 SEER2 EFFICIENCY: This mini split heat pump split system is designed with a operating cooling range of -13° to 122°F and heating range of -13° to 75° F outdoor temperatures.
- PRE-CHARGED UNIT: The inverter compressor modulates BTU output and comes fully pre-charged with enough refrigerant line set. Please note this NOT a DIY mini split AC and requires a professional to install the lines.
- WiFi ENABLED CONTROLS: Control your comfort from anywhere with ACiQ’s built-in WiFi. Use the ACiQ app on your phone or tablet to adjust temperature, settings, and schedules on the go. Plus, it works with Amazon Alexa and Google Assistant for easy, hands-free control.
| Noise | 28 Decibels |
|---|---|
| Voltage | 230 Volts |
| Wattage | 4140 watts |
| Capacity | 3 Tons |
| Room Type | Commercial Space |
| Brand Name | ACiQ |
| Efficiency | 18 SEER2 |
| Floor Area | 1600 Square Feet |
| Model Name | Mini-split AC/HP |
| Start Year | 2023 |
| Unit Count | 1.0 Count |
| Filter Type | Washable filter |
| Form Factor | Mini-split System |
| Item Weight | 214.28 Pounds |
| Refrigerant | R454B |
| Manufacturer | ACiQ |
| Model Number | ACIQ-36W-HP230C / ACIQ-36Z-HP230C |
| Power Source | 208/230v, 1-Phase, 60 Hz |
| Cooling Power | 36000 British Thermal Units |
| Inverter Type | Has Inverter |
| Warranty Type | 7yr parts and 12yr compressor with online registration |
| Control Method | Remote |
| BEE Star Rating | 4 Star |
| Compressor Type | rotary_scroll |
| Controller Type | Remote Control |
| Installation Type | Single Zone Mini-split System |
| Additional Features | Sleep Mode, Eco Mode, Turbo Mode, 24-Hour Timer, Follow Me, and Silent Mode |
| Included Components | Outdoor Condenser, Indoor Air Handler, Line Set, Control/Power Cables, Remote Control with Batteries and Mount, Mounting Plate, Drain Accessories, and a Complete Screws with Anchors |
| Warranty Description | 7yr parts and 12yr compressor with online registration |
| Is Outdoor Unit Required | Yes |
| Item Dimensions D x W x H | 11.1"D x 49.57"W x 14.25"H |
| Outdoor Unit Compatibility | Requires New Outdoor Unit |
| Air Conditioner Application | Commercial |
| Window Opening Maximum Width | 49 Inches |
| Window Opening Minimum Width | 49 Centimeters |
| Window Opening Maximum Height | 14.25 Inches |
| Window Opening Minimum Height | 14.25 Inches |
| Seasonal Energy Efficiency Ratio SEER | 18.0 |
