PNI Radio CB Escort HP 6500 ASQ with CB ML70 Antenna

Product identificationProduct code PNI-PACK61General features CB RadioAM-FM broadcast band typeFrequent 26.965-27.405 MHz40 AM / FM channel1W speaker audio powerSensitivity (20dB SINAD) greater than 1 µV (AM / FM)4 W emission powerModulation 80 - 90%Power supply 12 VMaximum consumption 2ADimensions / Weight 110 X 120 X 28/385 gSpecial features CB RadioAdjustable ASQ 28 levelsSQ - SquelchScan channelsRF Gain 9 levelsLock the keyboardEmergency channel button 9/19Features radio antennaWorking frequency 26 - 28 MhzNumber of channels 90Maximum applied power 200 WS.W.R. minimum in the center of the band less than 1.2Antenna length 70 cm (magnetic base included)Working distance 7 kmImpeding 50 OhmsMaterial Stainless steelTip connector PL259Hole diameter 16 mmMagnetic base includedDiameter of magnetic base 145 mmCable length 4mThe package containsCB RadioCB radio antennaMagnetic basePL259 plugRG58 cable 4 m

• CB PNI Escort The HP 6500 Escort provides FM radio communication that is used in Romania but also in the AM band when travelling outside the country. In addition to the type of bandwidth, you can also select the frequency band required to use the transmitter in other European countries.
• The PNI Escort HP 6500 is equipped with a Digital Automatic Squelch. The dual manual and automatic squelch mode provides 28 and 9 levels with the RF gain function to fine-tune the receiver.
• The length of the antenna is a very important factor that can affect the communication distance. The longer the antenna is, the greater the range. The PNI ML70 antenna has a length of 70 cm (including magnetic base).
• The PNI 145 / PL magnetic base is equipped with a 4 m cable that is sufficient to attach the antenna to the dome. The diameter is 145 mm and the magnet ensures stability of the antenna even at high speeds.
